LynH-3XD series (LynH-3XD-2T)
Capacity: 0.5, 1, 2, 3, 5, 8, 10, 20, 30T
Product Description:
The innovative load cell features an I-shaped cross-section design in its strain element, which samples shear strain from the blind plate. This structural configuration delivers exceptional resistance to eccentric loading, lateral forces, and impact shocks, ensuring stable performance in dynamic weighing environments.
Key advantages include:
High Precision: Advanced strain-gauge technology and precision manufacturing ensure measurement accuracy within strict tolerances.
Robust Sealing: Multi-layer potting compound provides hermetic sealing against moisture, dust, and corrosion, extending service life in harsh conditions.
Durable Surface Treatment: Bright, rust-resistant plating protects the alloy steel body from environmental degradation.
Reliable Signal Transmission: High-quality shielded cable with reinforced insulation ensures stable data transfer even in electrically noisy environments.
Beyond standard configurations, custom bearing structures are available to meet specific installation requirements. This versatility makes it ideal for integration into various electronic weighing systems, including truck scales, platform scales, hopper scales, and industrial weighing applications requiring high reliability and accuracy under demanding conditions.
